Description
ข้อมูลจำเพาะทางเทคนิค
ยี่ห้อ /ฺBrand : Suntree
Model : SHLX-PV2/2
แรงดันขาเข้า/Max Input Voltage: 600V
Max Continuous Input Current: 16A
Mppt Voltage Range: 7 ~ 60V
Rate Output Voltage: 42V
Max Continuous Out Current: 16A
Maximum Input Power : 600W
Max System Voltage : 1500V
72-Cell Module In Serial 1500V: 36 pcs
72-Cell Module In Serial 1100V: 26 pcs
72-Cell Module In Serial 1000V: 24 pcs
Peak Efficeincy : 99.5%
Peak Loss @5A : 0.9W
Peak Loss @8A : 1.4W
Peak Loss @12A : 2.9W
Peak Loss @15A : 4.5W
ขนาด / Diamension: 103×105.3×21.3 mm
น้ำหนัก/ Weight: 650g
Input/Output Cable Range: 150×1050 mm
Input/Output Cable Size: 4 mm2 / 4mm2
Terminal : MC4 (Compatible)
Protection Rating : IP67/NEMA6
Relative Humidity : 0 ~ 100 % RH
Operation Temperature Range: -40 ~ +65 °C
